型号Model |
KOM-800 |
KOM-1200 |
KOM-1500 |
|
输送带数量（条）Nos. of conveyor belt |
1 |
1 |
1 |
|
磨头数量（个） Nos. of polishing heads |
10 |
14 |
10 |
|
抛光磨头直径（mm）Dia. Of polishing heads |
100 |
100 |
100 |
|
倒角磨边轮数量(个) Nos. of chamfering diamond wheels |
5 |
6 |
5 |
|
气动倒边角磨头数量（个） Nos. of pneumatic chamfering heads. |
1 |
1 |
1 |
|
气动倒边角磨头直径（个）Dia. Of pneumatic chamfering heads. |
100 |
100 |
100 |
|
工作宽度Working width（mm） |
100-800 |
100-1200 |
100-1500 |
|
抛光速度Polishing speed（m/min） |
3-4 |
5-6 |
3-4 |
|
加工砖的厚度product thickness（mm） |
6-20 |
6-20 |
6-20 |
|
总功率Total power(KW) |
22 |
26 |
22 |
|
耗水量water consumption(L/min) |
350 |
490 |
350 |
|
耗电量Power consumption(KW/h) |
10 |
12 |
10 |
|
耗气量 air consumption(L/min) |
50 |
55 |
50 |
|
外型尺寸overall size(mm) |
7500*2200*1680 |
8000*2200*1680 |
7500*2800*1680 |
|
重量weight(Kg) |
5000 |
5500 |
5000 |
